TL6304AF300QG
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.05A 12V
PDF
/
Inventory: 6165
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Actuator Height off PCB, Vertical 3.40mm
Switch Travel 0.25mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 6.20mm x 6.20mm
Actuator Orientation Top Actuated
Operating Force 300gf
Mechanical Life 100,000 Cycles
Illumination Non-Illuminated
Throw Configuration SPST
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Termination Style SMD (SMT) Tab
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series TL6304
Published 2005
Packaging Tape & Reel (TR)
Physical
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Silver
