TL3302AF130QG
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.05A 12V
PDF
/
Buying Options
Total Price: USD $0.41
Unit Price: USD $0.4136
≥1 USD $0.4136
≥10 USD $0.39512
≥100 USD $0.379456
≥500 USD $0.329472
≥1000 USD $0.300608
≥3000 USD $0.279365
Inventory: 1283
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.016 inch
Body Height 3.9116mm
Technical
Actuator Height off PCB, Vertical 4.30mm
Switch Travel 0.25mm
Contact Function ON-OFF
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 6.00mm x 3.50mm
Contact (DC) Max Rating R Load 0.05A@50VDC
Actuator Orientation Top Actuated
Contact Timing SNAP ACTION
Operating Force 130gf
Switch Type KEYPAD SWITCH
Mechanical Life 40,000 Cycles
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 100000 Cycle(s)
Dielectric Withstanding Voltage 1000VRMS V
Contact Current(DC)-Max 0.05A
Insulation Resistance 100000000Ohm
Contact Resistance 0.02mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Rectangular Button
Body Breadth 3.5052 mm
Body Length or Diameter 5.9944mm
Termination Style Gull Wing
Current Rating 50mA
Voltage - Rated DC 12V
Additional Feature PACKAGE REEL
ECCN Code EAR99
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Tactile Feedback
JESD-609 Code e4
Series TL3302
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -20°C~70°C
Physical
Terminal Material BRASS
Actuator Material Polyphenylene Sulfide (PPS)
Insulation Material POLYPHENYLENE SULPHIDE
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Silver
Supply Chain
Factory Lead Time 11 Weeks
