TL3301SPF160QG
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
E-SWITCH - TL3301SPF160QG - Tactile Switch, TL3301 Series, Top Actuated, Surface Mount, Square Button, 160 gf, 50mA at 12VDC
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.4048
≥1 USD $0.4048
≥10 USD $0.39336
≥100 USD $0.379104
≥500 USD $0.327976
≥1000 USD $0.298813
Inventory: 1749
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Actuator Length 2.9mm
Width 6mm
Length 6mm
Technical
Actuator Height off PCB, Vertical 7.50mm
Switch Travel 0.25mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 6.00mm x 6.00mm
Actuator Orientation Top Actuated
Illumination Type Illuminated, Non-Illuminated
Operating Force 160gf
Contact Current Rating 50mA
Mechanical Life 100,000 Cycles
Max Voltage Rating (DC) 12V
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 100000 cycles
Contact Resistance 100mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Plunger for Cap
Termination Style Gull Wing
Current Rating 50mA
Orientation Straight
Voltage - Rated DC 12V
Min Operating Temperature -20°C
Max Operating Temperature 70°C
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series TL3301
Published 2006
Packaging Cut Tape (CT)
Operating Temperature -20°C~70°C
Physical
Actuator Material Polyamide (PA), Nylon
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Silver
Contact Material Silver
Supply Chain
Factory Lead Time 10 Weeks
