TL3301DF260RG
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACTILE SPST-NO 0.05A 12V
PDF
/
Buying Options
Total Price: USD $1.16
Unit Price: USD $1.1616
≥1 USD $1.1616
≥10 USD $1.1132
≥100 USD $1.046496
≥500 USD $0.903936
Inventory: 11135
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Body Height 3.6mm
Technical
Number of Switches 1
Actuator Height off PCB, Vertical 13.00mm
Switch Travel 0.25mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 6.00mm x 6.00mm
Contact (DC) Max Rating R Load .05A@50VDC
Actuator Orientation Top Actuated
Operating Force 260gf
Switch Type KEYPAD SWITCH
Mechanical Life 100,000 Cycles
Illumination Non-Illuminated
Contact Current(DC)-Max 0.05A
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Body Breadth 6 mm
Body Length or Diameter 6mm
Termination Style Gull Wing
Packing Method TAPE AND REEL
HTS Code 8536.50.90.40
Terminal Finish SILVER
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series TL3301
Packaging Cut Tape (CT)
Operating Temperature -20°C~70°C
Physical
Actuator Material Polyamide (PA), Nylon
Surface Mount NO
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
