TL3301AF100QG
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Switches / Tactile Switches
Description
Tactile Switches SMT Tact Switch SPST-NO 0.05A 12V
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.3696
≥1 USD $0.3696
≥10 USD $0.35552
≥100 USD $0.334752
≥500 USD $0.290664
≥1000 USD $0.263718
≥3000 USD $0.245309
Inventory: 10840
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SMD/SMT
Actuator Material Polyamide (PA), Nylon
Technical
Operating Temperature -20°C~70°C
Packaging Tape & Reel (TR)
Published 2006
Series TL3301
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
ECCN Code EAR99
Terminal Finish Silver (Ag)
HTS Code 8536.50.90.40
Voltage - Rated DC 12V
Packing Method TAPE AND REEL
Current Rating 50mA
Termination Style Gull Wing
Body Length or Diameter 6mm
Body Breadth 6 mm
Actuator Type Standard
Circuit SPST-NO
Switch Function Off-Mom
Contact Current(DC)-Max 0.05A
Throw Configuration SPST
Illumination Non-Illuminated
Mechanical Life 100,000 Cycles
Switch Type KEYPAD SWITCH
Operating Force 100gf
Actuator Orientation Top Actuated
Contact (DC) Max Rating R Load .05A@50VDC
Outline 6.00mm x 6.00mm
Contact Rating @ Voltage 0.05A @ 12VDC
Switch Travel 0.25mm
Actuator Height off PCB, Vertical 5.00mm
Number of Switches 1
Dimensions
Body Height 3.6mm
Compliance
RoHS Status ROHS3 Compliant
