TL1265AQRGRN
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
Round Button TL1265 Through Hole Top Actuated Tactile Switch 8.50mm 50mA 12V 0.05A @ 12VDC
PDF
/
Inventory: 4143
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Actuator Height off PCB, Vertical 8.50mm
Switch Travel 0.20mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 7.00mm x 6.80mm
Actuator Orientation Top Actuated
Operating Force 160gf
Switch Type KEYPAD SWITCH
Mechanical Life 500,000 Cycles
Illumination Non-Illuminated
Throw Configuration SPST
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Round Button
Termination Style PC Pin
Current Rating 50mA
Voltage - Rated DC 12V
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Green Cap
JESD-609 Code e4
Series TL1265
Published 2011
Packaging Bulk
Operating Temperature -20°C~70°C
Physical
Mounting Type Through Hole
Mount Through Hole
Contact Material Silver
Supply Chain
Factory Lead Time 10 Weeks
