LL3301DF065QJ
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
Standard LL3301 Surface Mount Top Actuated Tactile Switch 13.00mm 0.05A 12V 0.05A @ 12VDC
PDF
/
Buying Options
Total Price: USD $0.73
Unit Price: USD $0.7304
≥1 USD $0.7304
≥10 USD $0.70752
≥100 USD $0.484114
≥500 USD $0.448756
≥1000 USD $0.380758
≥3000 USD $0.353566
Inventory: 974
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 6mm
Length 6mm
Height 13mm
Technical
Contact Bounce Time-Max 10ms
Number of Switches 1
Actuator Height off PCB, Vertical 13.00mm
Switch Travel 0.25mm
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 6.00mm x 6.00mm
Contact (DC) Max Rating R Load .05A@12VDC
Actuator Orientation Top Actuated
Operating Force 65gf
Switch Type KEYPAD SWITCH
Illumination Non-Illuminated
Throw Configuration SPST
Contact Current(DC)-Max 0.05A
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Voltage - Rated AC 12V
Termination Style J Lead
Current Rating 50mA
HTS Code 8536.50.90.40
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series LL3301
Published 2006
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Silver
Supply Chain
Factory Lead Time 11 Weeks
