320.2E11RED
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
Tactile Switches SPST RED PC MT
PDF
/
Inventory: 4966
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.178 inch
Length - Termination 0.157 inch
Body Height 7.493mm
Technical
Actuator Height off PCB, Vertical 12.00mm
Switch Travel 0.60mm
PCB Hole Count 6
Contact Rating @ Voltage 0.025A @ 50VDC
Outline 12.40mm x 12.40mm
Contact (DC) Max Rating R Load 0.025A@50VDC
Actuator Orientation Top Actuated
Illumination Color Red
Illumination Type LED, Non-Illuminated
Operating Force 135gf
Switch Type PUSHBUTTON SWITCH
Mechanical Life 1,000,000 Cycles
Max Voltage Rating (DC) 50V
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 1e+06 cycles
Dielectric Withstanding Voltage 500VRMS V
Contact Current(DC)-Max 0.025A
Insulation Resistance 1000000000Ohm
Contact Resistance 50mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Rectangular Button
Body Breadth 12.446 mm
Termination Style PC Pin
Current Rating 25mA
Orientation Straight
Voltage - Rated DC 50V
Color Black
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Red Cap
Series 320
Packaging Bulk
Operating Temperature -20°C~70°C
Physical
End Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
Center Contact Material STAINLESS STEEL
Actuator Material Polycarbonate (PC)
Housing Material Nylon
Mounting Type Through Hole
Mount Through Hole
Contact Plating Silver
Supply Chain
Factory Lead Time 10 Weeks
