320.21E11GRN
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
SWITCH TACT SPST-NO 0.025A 50V
PDF
/
Inventory: 7944
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Silver
Mount Through Hole
Mounting Type Through Hole
Housing Material NYLON
Actuator Material Polycarbonate (PC)
Center Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
End Contact Material COPPER ALLOY
Technical
Operating Temperature -20°C~70°C
Packaging Bulk
Series 320
Feature Green Cap
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Additional Feature WITHOUT GROUND TERMINAL
Voltage - Rated DC 50V
Orientation Vertical
Current Rating 25mA
Termination Style PC Pin
Body Breadth 12.3952 mm
Actuator Type Rectangular Button
Circuit SPST-NO
Switch Function Off-Mom
Contact Resistance 0.01mOhm
Insulation Resistance 1000000000Ohm
Contact Current(DC)-Max 0.3A
Dielectric Withstanding Voltage 1000VRMS V
Electrical Life 1000000 Cycle(s)
Throw Configuration SPST
Illumination Non-Illuminated
Mechanical Life 1,000,000 Cycles
Contact Current Rating 25mA
Operating Force 135gf
Actuator Orientation Top Actuated
Contact (DC) Max Rating R Load 0.3A@50VDC
Outline 12.40mm x 12.40mm
Contact Rating @ Voltage 0.025A @ 50VDC
PCB Hole Count 4
Contact Function ON-OFF
Switch Travel 0.60mm
Actuator Height off PCB, Vertical 12.00mm
Dimensions
Length 22mm
Width 12.4mm
Body Height 8.001mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
