320.09E11WHT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Tactile Switches
Description
Tactile Switches Tactile PB WHT Cap SPST-NO 0.025A 50V
PDF
/
Buying Options
Total Price: USD $5.16
Unit Price: USD $5.163636
≥1 USD $5.163636
≥216 USD $2.061253
≥540 USD $1.991669
≥972 USD $1.957534
Inventory: 1417
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.346 inch
Length - Termination 0.158 inch
Body Height 7.3914mm
Technical
Actuator Height off PCB, Vertical 15.30mm
Switch Travel 0.60mm
Contact Function ON-OFF
PCB Hole Count 4
Contact Rating @ Voltage 0.025A @ 50VDC
Outline 12.40mm x 12.40mm
Contact (DC) Max Rating R Load 0.3A@50VDC
Actuator Orientation Top Actuated
Operating Force 135gf
Switch Type PUSHBUTTON SWITCH
Mechanical Life 1,000,000 Cycles
Max Voltage Rating (DC) 50V
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 1e+06 cycles
Dielectric Withstanding Voltage 1000VRMS V
Contact Current(DC)-Max 0.3A
Insulation Resistance 1000000000Ohm
Contact Resistance 50mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Round Button
Body Breadth 12.3952 mm
Body Length or Diameter 15.875mm
Termination Style PC Pin
Current Rating 25mA
Orientation Straight
Voltage - Rated DC 50V
Additional Feature WITHOUT GROUND TERMINAL
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature White Cap
Series 320
Packaging Bulk
Operating Temperature -20°C~70°C
Physical
Terminal Material COPPER ALLOY
Actuator Material Polycarbonate (PC)
Housing Material Nylon
Mounting Type Through Hole
Mount Through Hole
Contact Material Silver
Supply Chain
Factory Lead Time 10 Weeks
