KSF0M511

C&K
RoHS
/
Package /
Category Switches / Tactile Switches
Description SWITCH TACTILE SPST-NO 0.05A 32V
PDF
/
Inventory: 6609
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Dust Tight, IP60
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant

Dimensions

Width 7.4mm
Length 7.4mm

Technical

Actuator Height off PCB, Vertical 2.60mm
Switch Travel 0.30mm
Contact Rating @ Voltage 0.05A @ 32VDC
Outline 7.40mm x 7.30mm
Actuator Orientation Top Actuated
Illumination Type Non-Illuminated
Operating Force 500gf
Contact Current Rating 50mA
Mechanical Life 100,000 Cycles
Illumination Non-Illuminated
Throw Configuration SPST
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Without
Termination Style PC Pin
Current Rating 50mA
Ingress Protection IP60 - Dust Tight
Orientation Vertical
Voltage - Rated DC 32V
Power Rating 1W
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series KSF
Published 2003
Packaging Bulk
Operating Temperature -40°C~85°C

Physical

Mounting Type Through Hole
Mount Through Hole
Contact Plating Silver
Contact Material Silver
