ADTSM63SV
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Switches / Tactile Switches
Description
Standard ADTS Surface Mount Top Actuated Tactile Switch 7.00mm 0.05A 250VAC V 0.05A @ 12VDC
PDF
/
Inventory: 8057
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 3.5mm
Technical
Number of Switches 1
Body Color BLACK
Actuator Height off PCB, Vertical 7.00mm
Switch Travel 0.25mm
Actuator Color BLACK
Contact Rating @ Voltage 0.05A @ 12VDC
Outline 6.20mm x 6.20mm
Contact (DC) Max Rating R Load .05A@12VDC
Actuator Orientation Top Actuated
Operating Force 320gf
Switch Type KEYPAD SWITCH
Max Voltage Rating (DC) 12V
Illumination Non-Illuminated
Throw Configuration SPST
Electrical Life 100000 cycles
Dielectric Withstanding Voltage 250VAC V
Contact Current(DC)-Max 0.05A
Insulation Resistance 100000000Ohm
Contact Resistance 100mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Standard
Body Breadth 6.2 mm
Body Length or Diameter 6.2mm
Termination Style Gull Wing
Current Rating 50mA
Orientation Straight
Voltage - Rated DC 12V
HTS Code 8536.50.90.40
ECCN Code EAR99
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Tactile Feedback
JESD-609 Code e4
Series ADTS
Packaging Bulk
Operating Temperature -25°C~70°C
Physical
Terminal Material BRASS
Actuator Material Polyamide (PA), Nylon
Housing Material STAINLESS STEEL
Insulation Material THERMOPLASTIC
Package / Case SMD/SMT
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Silver
Contact Material Bronze, Silver
Supply Chain
Factory Lead Time 8 Weeks
