WO-3709V-03
RoHS
RoHS compliant
RoHS compliantPackage /
Category Motors, Solenoids, Driver Boards/Modules / Stepper Motors
Description
STEPPER MOTOR
PDF
/
Buying Options
Total Price: USD $40.42
Unit Price: USD $40.4184
≥1 USD $40.4184
≥10 USD $39.71792
≥100 USD $39.02184
≥500 USD $38.325056
≥1000 USD $37.628272
≥3000 USD $37.070792
Inventory: 62
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length - Shaft and Bearing 0.787 20.00mm
Diameter - Shaft 0.197 (5.00mm)
Technical
Rotor Inertia 0.308gcm2
NEMA Frame Size 14
Torque - Holding (oz-in / mNm) 16 / 113
Steps per Revolution 400
Step Angle 0.9°
Coil Type Bipolar
Coil Resistance 3Ohm
Termination Style Wire Leads
Current Rating (Amps) 1.2A
Voltage - Rated 24VDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Double Round Shaft
Size / Dimension Square - 1.440Lx1.440W 36.58mmx36.58mm
Packaging Tray
Operating Temperature -20°C~50°C
Physical
Mounting Hole Spacing 1.220 (31.00mm)
Supply Chain
Factory Lead Time 16 Weeks
