PE-65812
RoHS
/
Package /
Category Transformers / Specialty Transformers
Description
Audio Transformer 1:1 2000Vrms 8Term. Gull Wing SMD
PDF
/
Buying Options
Total Price: USD $3.46
Unit Price: USD $3.46275
≥1 USD $3.46275
≥10 USD $2.84145
≥100 USD $2.75215
≥500 USD $2.6638
≥1000 USD $2.57545
Inventory: 31003
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 15.24mm
Length 12.06mm
Height Seated (Max) 0.340 8.64mm
Height 8.64mm
Technical
Return Loss 20 dB
Turns Ratio - Primary:Secondary 1:1
Isolation Voltage 2kV
Lead/Base Style Gull Wing
Inductance 2.5mH
Frequency 55MHz
Depth 15.24mm
Shielding Unshielded
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.475Lx0.460W 12.07mmx11.68mm
Published 2006
Physical
Number of Pins 8
Mounting Type Surface Mount
Mount Surface Mount
