CAP018DG
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Specialized ICs
Description
IC CAP DISCHRG 1000V 3500NF 8SO
PDF
/
Buying Options
Total Price: USD $4.01
Unit Price: USD $4.0128
≥1 USD $4.0128
≥10 USD $3.2927
≥100 USD $3.1901
≥500 USD $3.08655
≥1000 USD $2.98395
Inventory: 6225
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Input Current 21.7μA
Series Resistance 200kOhm
Clamping Voltage 1kV
Max Supply Voltage 230V
Temperature Grade OTHER
Pin Count 8
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Rated 230V
Applications Converter, ACDC
Min Operating Temperature -10°C
Max Operating Temperature 105°C
Terminal Finish MATTE TIN
Type Capacitor Discharge
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
JESD-609 Code e3
Series CAPZero?
Published 2011
Packaging Tube
Physical
Weight 540.001716mg
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
