SP-3005Y
RoHS
RoHS compliant
RoHS compliantPackage /
Category Audio Products / Speakers
Description
SPEAKER, 87DB SENSITIVITY, 30MM
PDF
/
Buying Options
Total Price: USD $0.88
Unit Price: USD $0.875704
≥1 USD $0.875704
Inventory: 1116
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.209 5.30mm
Technical
Efficiency - Testing 1W/500mm
Efficiency - Type Sound Pressure Level (SPL)
Efficiency - dBA 87.00
Port Location Top
Power - Rated 1W
Frequency Range 520Hz~8kHz
Power - Max 1.5W
Frequency - Self Resonant 650Hz
Impedance 8Ohm
Technology Magnetic
Type General Purpose
Termination Solder Pads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 1.181Dia 30.00mm
Series SP Micro Speaker
Operating Temperature -20°C~60°C
Physical
Material - Magnet Nd-Fe-B
Material - Cone Polyester, Polyethylene Terephthalate (PET)
Shape Round
Supply Chain
Factory Lead Time 8 Weeks
