S101N11
RoHS
/
Package 4-SIP
Category Relays / Solid State Relays
Description
RELAY SSR 120VAC 1.6A TRIAC 4SIP
PDF
/
Buying Options
Total Price: USD $6.57
Unit Price: USD $6.569752
≥1 USD $6.569752
≥200 USD $2.621861
≥500 USD $2.533897
≥1000 USD $2.490571
Inventory: 6678
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 5.5mm
Length 26mm
Height 21mm
Technical
Isolation Voltage-Max 3000V
Voltage - Load 80V~120V
Relay Type Relay
Optoelectronic Device Type TRIGGER OUTPUT SSR
Throw Configuration SPST
Output Current 1.6A
Voltage - Input 1.2VDC
Circuit SPST-NO (1 Form A)
Number of Elements 1
Output Type AC
Operating Temperature (Min) -25°C
Operating Temperature (Max) 80°C
Termination Style PC Pin
Reach Compliance Code unknown
Terminal Finish Tin/Lead (Sn/Pb)
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Series S101
Published 1999
Packaging Tube
Physical
Package / Case 4-SIP
Mounting Type Through Hole
Mount Through Hole
