EL100D10-05
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Relays / Solid State Relays
Description
SOLID STATE RELAY, 5VDC, 3-100VDC, 10A
PDF
/
Buying Options
Total Price: USD $40.77
Unit Price: USD $40.7704
≥1 USD $40.7704
≥10 USD $38.8344
≥100 USD $37.0656
≥500 USD $35.9744
Inventory: 114
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Chassis Mount, Panel, Screw
Mounting Type Chassis Mount
Package / Case Module
Number of Pins 4
Weight 14.399999g
Technical
Packaging Bulk
Series EL
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
Resistance 10mOhm
Max Operating Temperature 80°C
Min Operating Temperature -30°C
Depth 21.1mm
Current Rating 10A
Termination Style Quick Connect - 0.187/0.250
Approval Agency CE, UL
Output Type DC
Max Output Current 10A
Min Supply Voltage (DC) 3V
Isolation Voltage 2.5kV
Max Supply Voltage (DC) 100V
Load Current 10A
On-State Resistance (Max) 10mOhms
Voltage - Load 3V~100V
Relay Type Relay
Max Output Voltage 100V
Turn On Delay Time 1 ms
Max Voltage Rating (DC) 100V
Throw Configuration SPST
Output Current 10A
Voltage - Input 4V~8VDC
Circuit SPST-NO (1 Form A)
Operating Supply Voltage 100V
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 21mm
Length 36mm
Height 26mm
