AQZ105D
RoHS
RoHS compliant
RoHS compliantPackage 4-SIP
Category Relays / Solid State Relays
Description
SSR RELAY SPST-NO 2.3A 0-100V
PDF
/
Buying Options
Total Price: USD $9.09
Unit Price: USD $9.0904
≥1 USD $9.0904
≥10 USD $8.51928
≥100 USD $7.572576
≥500 USD $7.194
≥1000 USD $6.815336
≥3000 USD $6.058061
Inventory: 384
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 4-SIP
Number of Pins 4
Supplier Device Package 4-SIL
Technical
Packaging Tube
Published 2004
Series PhotoMOS? AQZ
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Resistance 170mOhm
Termination Style PC Pin
Output Voltage 100V
Output Type DC
Max Output Current 2.3A
Circuit SPST-NO (1 Form A)
Voltage - Input 1.4VDC
Throw Configuration SPST
Max Output Voltage 100V
Relay Type Relay
Voltage - Load 0V~100V
On-State Resistance (Max) 170mOhms
Load Current 2.3A
Dimensions
Height 12.5mm
Length 21mm
Width 3.5mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
