RoHS
RoHS RoHS compliant
Package Module
Category Relays / I/O Relay Modules
Description OUTPUT MODULE DC STD 20MA 5VDC
PDF
/
Inventory: 7678
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 5 Weeks

Physical

Mount PCB, Screw
Package / Case Module
Number of Pins 5

Technical

Packaging Box
Published 2000
Series 6
Feature Hold Down Screw
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) Not Applicable
Type DC Output Module
Max Operating Temperature 80°C
Min Operating Temperature -40°C
Color Red
Voltage - Rated 5V
Voltage - Rated DC 5V
Depth 31.7mm
Style Standard
Current Rating 20A
Approval Agency CSA, UL
Operating Supply Voltage 5V
Number of Channels 1
Voltage - Input 5VDC
Current - Output 3.5A
Throw Configuration SPST
Turn On Delay Time 100 μs
Voltage - Output 3V~60VDC
Turn-Off Delay Time 100 μs
Turn On Time 0.10ms
Isolation Voltage 4kV
Turn Off Time 0.10ms
Current - Input 20mA
Number of Analog Outputs 1

Dimensions

Height 38.1mm
Length 43.1mm
Width 15.2mm

Compliance

REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
