G3VM-355F
RoHS
/
Package 8-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
RELAY SPST-NO/NC 100MA 0-350V
PDF
/
Buying Options
Total Price: USD $12.79
Unit Price: USD $12.78795
≥1 USD $12.78795
≥10 USD $10.49275
≥100 USD $10.165
≥500 USD $9.83725
≥1000 USD $9.5095
Inventory: 2505
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 21 Weeks
Physical
Mount PCB, Surface Mount
Mounting Type Surface Mount
Package / Case 8-SMD (0.300, 7.62mm)
Number of Pins 8
Technical
Packaging Tube
Published 2001
Series G3VM
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
Resistance 50Ohm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Depth 6.4mm
Termination Style Gull Wing
Output Type AC, DC
Max Output Current 120mA
Number of Elements 2
Circuit SPST-NO + SPST-NC (1 Form A and B)
Voltage - Input 1.15VDC
Output Current 120mA
Throw Configuration DPST, SPST
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Max Output Voltage 350V
Max Input Voltage 1.3V
Relay Type Relay
Voltage - Load 0V~350V
Forward Current-Max 0.025A
On-State Resistance (Max) 50Ohm
Max Input Current 50mA
Input Current 50mA
On-State Current-Max 0.1A
Load Current 100mA
Isolation Voltage 2.5kV
Dimensions
Height 3.65mm
Length 9.66mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
