G3VM-21LR(TR10)
RoHS
/
Package 4-SMD (0.165, 4.20mm)
Category Relays / Solid State Relays
Description
SSR RELAY SPST-NO 160MA 0-20V
PDF
/
Buying Options
Total Price: USD $10.02
Unit Price: USD $10.016114
≥1 USD $10.016114
≥200 USD $3.996468
≥500 USD $3.863865
≥1000 USD $3.796907
Inventory: 9665
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 21 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-SMD (0.165, 4.20mm)
Number of Pins 4
Technical
Packaging Tape & Reel (TR)
Published 2001
Series G3VM
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination SMD/SMT
Resistance 8Ohm
Additional Feature UL RECOGNIZED
Reach Compliance Code unknown
Termination Style SMD (SMT) Tab
Operating Temperature (Max) 60°C
Operating Temperature (Min) 25°C
Output Type AC, DC
Max Output Current 160mA
Number of Elements 1
Circuit SPST-NO (1 Form A)
Voltage - Input 1.15VDC
Throw Configuration SPST
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Max Output Voltage 20V
Max Input Voltage 1.3V
Relay Type Relay
Voltage - Load 0V~20V
Forward Current-Max 0.03A
On-State Resistance (Max) 8Ohm
Max Input Current 50mA
On-State Current-Max 0.16A
Isolation Voltage-Max 1500V
Compliance
RoHS Status RoHS Compliant
