PVN012SPBF
RoHS
RoHS compliant
RoHS compliantPackage 6-SMD (0.300, 7.62mm)
Category Relays / Solid State Relays
Description
SSR RELAY SPST-NO 2.5A 0-20V
PDF
/
Buying Options
Total Price: USD $0.64
Unit Price: USD $0.6365
≥1 USD $0.6365
≥10 USD $0.5225
≥100 USD $0.50635
≥500 USD $0.48925
≥1000 USD $0.4731
Inventory: 1684
Minimum: 1
-
+
Technical Details
Physical
Mount PCB, Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD (0.300, 7.62mm)
Number of Pins 6
Technical
Packaging Tube
Published 2004
Series PVN, HEXFET?
Part Status Active
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Termination Gull Wing
Resistance 100mOhm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Capacitance 300pF
Voltage - Rated DC 20V
Current Rating 4.5A
Termination Style Gull Wing
Approval Agency UL
Output Voltage 20V
Output Type AC, DC
Number of Elements 1
Circuit SPST-NO (1 Form A)
Insulation Resistance 1 TΩ
Number of Channels 1
Voltage - Input 1.2VDC
Output Current 2.5A
Throw Configuration SPST
Input Type DC
Turn On Delay Time 5 ms
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Forward Current 25mA
Max Output Voltage 20V
Rise Time 5 ms
Relay Type Relay
Fall Time (Typ) 500 μs
Turn-Off Delay Time 500 μs
Voltage - Load 0V~20V
On-State Resistance (Max) 100mOhm
Max Input Current 25mA
Input Current 25mA
Isolation Voltage 4kV
Control Current 0.003A
Supply Chain
Factory Lead Time 16 Weeks
Dimensions
Height 3.42mm
Length 8.63mm
Width 6.47mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
