77.31.9.024.8050
RoHS
RoHS compliant
RoHS compliantPackage SSR with Integrated Heat Sink
Category Relays / Solid State Relays
Description
AC Zero Cross RoHS Compliant Active SPST Solid State Relay 10ms 80C 24VDC 104.5mm
PDF
/
Buying Options
Total Price: USD $174.5
Unit Price: USD $174.502791
≥1 USD $174.502791
≥200 USD $69.628339
≥500 USD $67.30188
≥1000 USD $66.151779
Inventory: 1095
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP20
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 22.5mm
Length 22.5mm
Height 104.5mm
Technical
Load Current 30A
Voltage - Load 48V~480V
Turn On Delay Time 10 ms
Throw Configuration SPST
Voltage - Input 24VDC
Max Voltage Rating (AC) 265V
Max Supply Voltage 24V
Circuit SPST-NO (1 Form A)
Operating Supply Voltage 24V
Output Type AC, Zero Cross
Termination Style Screw Terminal
Depth 120.3mm
Min Operating Temperature -20°C
Max Operating Temperature 80°C
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series 77
Packaging Bulk
Physical
Package / Case SSR with Integrated Heat Sink
Mounting Type DIN Rail
Mount DIN Rail
Supply Chain
Factory Lead Time 6 Weeks
