2106053-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Solid State Lighting Connectors
Description
CONN SSL HDR 3POS 3.5MM SOLDER
PDF
/
Buying Options
Total Price: USD $4.61
Unit Price: USD $4.6112
≥1 USD $4.6112
≥10 USD $4.0436
Inventory: 771
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Contact Material Brass
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Material Thermoplastic
Housing Material Liquid Crystal Polymer (LCP)
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Published 2011
Series SlimSeal
Feature Solder Retention
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Header, Male Pins
Number of Positions 3
Max Operating Temperature 221°C
Min Operating Temperature -40°C
Color Black
Number of Rows 1
Voltage - Rated 400V
Fastening Type Latch Lock
Current Rating (Amps) 3.5A 22-24AWG ; 5A 18-20AWG
Pitch 0.138 3.50mm
Orientation Straight
Ingress Protection IP67 - Dust Tight, Waterproof
Depth 8.02mm
Style Board to Cable/Wire
Current Rating 5A
Contact Finish Tin
Number of Contacts 3
Housing Color Black
ELV Compliant
Max Voltage Rating (AC) 250V
Max Current Rating 5A
Max Voltage Rating (DC) 250.25kV
Sealable Yes
Contact Current Rating 5A
Mating Cycles 30
Mating Post Length 6.477mm
Keyed No
Make First / Break Last No
Dimensions
Height 17.6276mm
Length 24.13mm
Width 7.9502mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
