009177001022006
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Solid State Lighting Connectors - Contacts
Description
9177 ROHS3Compliant Straight GENERAL PURPOSE SSL Contact, IDC UL94V-0 18AWG -40C~125C 15A
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.4344
≥1 USD $1.4344
≥10 USD $1.2496
≥100 USD $1.116896
Inventory: 882
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Phosphor Bronze
Mount Surface Mount
Mounting Type Surface Mount
Housing Material Polyamide (PA46), Nylon 4/6
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series 9177
JESD-609 Code e3
Feature Cap (Cover)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination Solder
ECCN Code EAR99
Connector Type Contact, IDC
Number of Rows 1
Voltage - Rated 600V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Current Rating (Amps) 15A per Contact
Orientation Straight
Depth 9mm
Style Board to Cable/Wire
Current Rating 15A
Contact Finish Tin
Housing Color Black
Wire Gauge 18 AWG
Max Current Rating 15A
Wire/Cable Gauge 18 AWG
Mating Cycles 3
Dimensions
Length 9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
