D0806-01
RoHS
/
Package /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
IC & Component Sockets 6P DIL IC SOCKET VERT 3 LVL WIRE WRAP
PDF
/
Inventory: 9443
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 196.9μin 5.00μm
Contact Finish Thickness - Mating 10.0μin 0.25μm
Technical
Pitch - Post 0.100 2.54mm
Termination Post Length 0.510 12.95mm
PCB Contact Row Spacing 0.3 mm
Mating Contact Pitch 0.1 inch
Contact Resistance 10mOhm
Contact Style RND PIN-SKT
Body Depth 0.193 inch
Body Breadth 0.4 inch
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number of Contacts 6
Body Length or Diameter 0.3 inch
Pitch - Mating 0.100 2.54mm
Reach Compliance Code not_compliant
Terminal Pitch 2.54mm
Current Rating (Amps) 1A
Contact Finish - Mating Gold
HTS Code 8536.69.40.40
Type DIP, 0.3 (7.62mm) Row Spacing
ECCN Code EAR99
Termination Wire Wrap
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Open Frame
Series D0
Published 2008
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Contact Material - Post Brass
Contact Material - Mating Beryllium Copper
Number of Positions or Pins (Grid) 6 (2 x 3)
Housing Material Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled
Mounting Type Through Hole
