A20-LCG
RoHS
/
Package /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
ICs Socket
PDF
/
Inventory: 3479
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 10.2mm
Length 25.4mm
Height 5.1mm
Technical
Pitch - Post 0.100 2.54mm
PCB Contact Row Spacing 0.3 mm
Dielectric Withstanding Voltage 500VAC V
Mating Contact Pitch 0.1 inch
Insulation Resistance 1000000000Ohm
Contact Style BELLOWED TYPE
Operating Temperature (Min) -55°C
Body Breadth 0.392 inch
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Number of Contacts 20
Pitch - Mating 0.100 2.54mm
Current Rating 1A
Terminal Pitch 2.54mm
Contact Finish - Mating Gold
HTS Code 8536.69.40.40
Type DIP, 0.3 (7.62mm) Row Spacing
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Open Frame
Physical
Number of Positions or Pins (Grid) 20 (2 x 10)
Housing Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Number of Pins 20
Mounting Type Through Hole
Mount Through Hole
Contact Material Bronze
