34-6822-90C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
Vertisockets? 800 ROHS3Compliant 2006 RECTANGULAR DIP, 0.6 (15.24mm) Row Spacing Socket UL94V-0 -55C~105C 3A 0.7inch
PDF
/
Inventory: 7132
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Horizontal, Through Hole
Mounting Type Through Hole, Right Angle, Horizontal
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Number of Positions or Pins (Grid) 34 (2 x 17)
Contact Material - Mating Beryllium Copper
Contact Material - Post Brass
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2006
Series Vertisockets? 800
JESD-609 Code e4
Feature Closed Frame
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type DIP, 0.6 (15.24mm) Row Spacing
Number of Positions 34
Additional Feature STANDARD: UL 94V-0
Contact Finish - Mating Gold
Terminal Pitch 2.54mm
Current Rating 3A
Pitch - Mating 0.100 2.54mm
Body Length or Diameter 1.7 inch
Number of Contacts 34
Contact Finish - Post Tin
PCB Contact Pattern RECTANGULAR
Body Breadth 0.7 inch
Lead Length 3.556mm
Body Depth 0.428 inch
Contact Style RND PIN-SKT
Mating Contact Pitch 0.1 inch
PCB Contact Row Spacing 0.2 mm
Termination Post Length 0.140 3.56mm
Pitch - Post 0.100 2.54mm
Dimensions
Contact Finish Thickness - Mating 30.0μin 0.76μm
Contact Finish Thickness - Post 200.0μin 5.08μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
