28-6553-18
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
STANDARD: UL 94V-0 ICs Socket
PDF
/
Buying Options
Total Price: USD $245.88
Unit Price: USD $245.879912
≥1 USD $245.879912
≥198 USD $98.107765
≥504 USD $94.829454
≥999 USD $93.210648
Inventory: 8725
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Post 200.0μin 5.08μm
Contact Finish Thickness - Mating 200.0μin 5.08μm
Technical
Pitch - Post 0.100 2.54mm
Termination Post Length 0.110 2.78mm
Dielectric Withstanding Voltage 1000VAC V
Mating Contact Pitch 0.1 inch
Insulation Resistance 1000000000Ohm
Contact Style SQ PIN-SKT
Body Depth 0.47 inch
Body Breadth 0.9 inch
Operating Temperature (Max) 250°C
PCB Contact Pattern RECTANGULAR
Number of Contacts 28
Body Length or Diameter 1.99 inch
Pitch - Mating 0.100 2.54mm
Terminal Pitch 2.54mm
Current Rating (Amps) 1A
Contact Finish - Mating Tin
Additional Feature STANDARD: UL 94V-0
Type DIP, ZIF (ZIP), 0.6 (15.24mm) Row Spacing
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Closed Frame
Series 55
Packaging Bulk
Physical
Contact Material - Post Beryllium Copper
Contact Material - Mating Beryllium Copper
Number of Positions or Pins (Grid) 32 (2 x 16)
Housing Material Polyphenylene Sulfide (PPS), Glass Filled
Mounting Type Through Hole
Supply Chain
Factory Lead Time 6 Weeks
