228-4817-00-0602J
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Sockets for ICs, Transistors
Description
CONN IC DIP SOCKET ZIF 28POS GLD
PDF
/
Buying Options
Total Price: USD $28.33
Unit Price: USD $28.3272
≥1 USD $28.3272
≥10 USD $24.80456
≥100 USD $23.73272
≥500 USD $22.96712
≥1000 USD $22.201432
≥3000 USD $20.97656
Inventory: 57
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Copper
Contact Plating Gold
Mount Through Hole
Mounting Type Connector
Number of Pins 28
Housing Material Polysulfone (PSU), Glass Filled
Body Material Glass, Polysulfone
Number of Positions or Pins (Grid) 28 (2 x 14)
Contact Material - Mating Beryllium Copper
Contact Material - Post Beryllium Copper
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2000
Series Textool?
Feature Closed Frame
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Type DIP, ZIF (ZIP), 0.4 (10.16mm) Row Spacing
Number of Positions 28
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Gender Female
Voltage - Rated 1kV
Contact Finish - Mating Gold
Current Rating (Amps) 1A
Pitch 2.54mm
Orientation Straight
Depth 11.9mm
Current Rating 1A
Pitch - Mating 0.100 2.54mm
Number of Contacts 28
Contact Finish - Post Gold
Contact Resistance 15mOhm
Row Spacing 10.16 mm
Termination Post Length 0.110 2.78mm
Pitch - Post 0.100 2.54mm
Dimensions
Length 50.5mm
Width 17.8mm
Contact Finish Thickness - Mating 30.0μin 0.76μm
Contact Finish Thickness - Post 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
