DB1CB1LB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
SWITCH SNAP ACTION SPDT 5A 125V
PDF
/
Buying Options
Total Price: USD $2.23
Unit Price: USD $2.228756
≥1 USD $2.228756
≥10 USD $2.102603
≥100 USD $1.983583
≥500 USD $1.87131
≥1000 USD $1.765382
Inventory: 6963
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Operating Position 0.420 (10.7mm)
Pretravel 0.157 (4.0mm)
Differential Travel 0.020 (0.5mm)
Overtravel 0.079 (2.0mm)
Operating Force 60gf
Mechanical Life 15,000,000 Cycles
Electrical Life 6,000 Cycles
Switch Function On-Mom
Circuit SPDT
Actuator Type Lever, Straight
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.110 (2.8mm)
Ingress Protection IP50 - Dust Protected
Current Rating (Amps) 5A AC 1A DC
Voltage - Rated DC 48V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series DB
Published 2012
Packaging Bulk
Operating Temperature -40°C~120°C
Physical
Mounting Type Chassis Mount
Supply Chain
Factory Lead Time 29 Weeks
