D2VW-5-2MS
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
Basic / Snap Action Switches MINIATURE BASIC SWITCH
PDF
/
Buying Options
Total Price: USD $17.93
Unit Price: USD $17.9256
≥1 USD $17.9256
≥10 USD $13.904
≥100 USD $11.342936
Inventory: 52
Minimum: 1
-
+
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Release Force 30gf
Operating Position 0.579 (14.7mm)
Pretravel 0.047 (1.2mm)
Differential Travel 0.016 (0.4mm)
Overtravel 0.040 (1.0mm)
Operating Force 200gf
Mechanical Life 10,000,000 Cycles
Max Voltage Rating (DC) 125V
Throw Configuration SPST
Electrical Life 100,000 Cycles
Max Voltage Rating (AC) 250V
Switch Function On-Mom
Circuit SPST-NC
Actuator Type Round (Pin Plunger)
Voltage - Rated AC 125V
Termination Style Wire Leads
Current Rating 5A
Ingress Protection IP67 - Dust Tight, Waterproof
Orientation Straight
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 30V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series D2VW
Published 2004
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Weight 7g
Mounting Type Chassis Mount
Mount Chassis Mount, Screw, Wire
Contact Material Silver
Supply Chain
Factory Lead Time 14 Weeks
