LS085R102F045C2C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
Lever Straight LS Chassis Mount Bulk Snap Switch 19.05mm 0.4VA AC/DC 1500VAC V 0.4VA@20VDC
PDF
/
Buying Options
Total Price: USD $2.49
Unit Price: USD $2.493197
≥1 USD $2.493197
Inventory: 8309
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Housing Material POLYBUTYLENE TEREPHTHALATE
Actuator Material POLYBUTYLENE TEREPHTHALATE
Center Contact Plating GOLD
Terminal Material COPPER ALLOY
End Contact Plating GOLD
Technical
Operating Temperature -25°C~85°C
Packaging Bulk
Published 2009
Series LS
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Termination Style Quick Connect - 0.250 (6.3mm)
Voltage - Rated AC 20V
Body Length or Diameter 28.9052mm
Body Breadth 10.3124 mm
Actuator Type Lever, Straight
Circuit SPST-NO
Switch Function Off-Mom
Contact Resistance 0.1mOhm
Insulation Resistance 100000000Ohm
Dielectric Withstanding Voltage 1500VAC V
Electrical Life 50,000 Cycles
Throw Configuration SPST
Mechanical Life 1,000,000 Cycles
Switch Type SNAP ACTING/LIMIT SWITCH
Operating Force 45gf
Contact Timing SNAP ACTION
Pretravel 0.161 (4.1mm)
Operating Position 0.610 (15.5mm)
Release Force 20gf
Contact (DC) Max Power Rating R Load 0.4VA@20VDC
Dimensions
Body Height 19.05mm
Compliance
RoHS Status ROHS3 Compliant
