LS0851500F160V2A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
SWITCH SNAP ACTION SPDT 15A 125V
PDF
/
Inventory: 3812
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
PCB Hole Count 5
Release Force 40gf
Operating Position 0.579 (14.7mm)
Pretravel 0.080 (2.0mm)
Contact Voltage(AC)-Max 250V
Contact (AC) Max Rating R Load 15A@250VAC
Operating Force 160gf
Switch Type SNAP ACTING/LIMIT SWITCH
Mechanical Life 1,000,000 Cycles
Electrical Life 50,000 Cycles
Dielectric Withstanding Voltage 1500VAC V
Insulation Resistance 100000000Ohm
Contact Resistance 0.1mOhm
Switch Function On-Mom
Circuit SPDT
Actuator Type Round (Pin Plunger)
Body Breadth 10.3124 mm
Body Length or Diameter 28.9052mm
Voltage - Rated AC 125V
Termination Style PC Pin
Current Rating 15A
Current Rating (Amps) 15A AC
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series LS
Published 2009
Packaging Bulk
Operating Temperature -25°C~85°C
Physical
Terminal Material COPPER ALLOY
Actuator Material POLYBUTYLENE TEREPHTHALATE
Housing Material POLYBUTYLENE TEREPHTHALATE
Mounting Type Through Hole, Right Angle
Mount Through Hole
Supply Chain
Factory Lead Time 11 Weeks
