831709C2.0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
Basic / Snap Action Switches SNSW 0.1A SLDR NONE
PDF
/
Inventory: 5985
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Material Silver
Mount Panel, Screw, Solder
Mounting Type Chassis Mount
Weight 1.7g
Technical
Operating Temperature -20°C~130°C
Packaging Bulk
Series 83170
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Max Operating Temperature 125°C
Min Operating Temperature -20°C
Voltage - Rated DC 4V
Current Rating (Amps) 100mA AC
Orientation Straight
Current Rating 6A
Termination Style Solder Lug
Voltage - Rated AC 250V
Actuator Type Round (Pin Plunger)
Circuit SPDT
Switch Function On-Mom
Max Voltage Rating (AC) 250V
Throw Configuration SPDT
Max Voltage Rating (DC) 250V
Mechanical Life 30,000,000 Cycles
Contact Current Rating 100mA
Operating Force 61gf
Overtravel 0.020 (0.5mm)
Differential Travel 0.006 (0.15mm)
Operating Position 0.330 (8.4mm)
Release Force 10gf
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Ratings IP67
