TFCGV2VA105AC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
Basic / Snap Action Switches Snap
PDF
/
Inventory: 5511
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Silver
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Housing Material Thermoplastic
Actuator Material Thermoplastic
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2012
Series TF
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Current Rating (Amps) 5A AC
Orientation Straight
Release Force 15gf
Operating Position 0.812 (20.6mm)
Pretravel 0.060 (1.5mm)
Differential Travel 0.015 (0.38mm)
Overtravel 0.030 (0.76mm)
Operating Force 90gf
Throw Configuration SPDT
Electrical Life 300,000 Cycles
Max Current Rating 5A
Max Voltage Rating (AC) 277V
Switch Function On-Mom
Circuit SPDT
Actuator Type Lever, Roller
Voltage - Rated AC 277V
Termination Style Quick Connect - 0.250 (6.3mm)
Current Rating 5A
Depth 10.2mm
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 39.9mm
