TFCDF5ST2540C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Snap Action, Limit Switches
Description
Switch Snap Action N.O./N.C. SPDT Lever Quick Connect 1A 125VAC 30VDC 0.08N Screw Mount
PDF
/
Inventory: 9862
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Gold
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Housing Material Thermoplastic
Actuator Material Thermoplastic
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2012
Series TF
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Voltage - Rated DC 30V
Current Rating (Amps) 1A AC/DC
Orientation Straight
Depth 10.2mm
Current Rating 1A
Termination Style Quick Connect - 0.187 (4.7mm)
Voltage - Rated AC 125V
Actuator Type Lever, Straight
Circuit SPDT
Switch Function On-Mom
Max Voltage Rating (AC) 125V
Max Current Rating 1A
Electrical Life 6,000 Cycles
Throw Configuration SPDT
Max Voltage Rating (DC) 30V
Operating Force 8.000gf
Overtravel 0.125 (3.2mm)
Differential Travel 0.055 (1.4mm)
Pretravel 0.250 (6.35mm)
Operating Position 0.600 (15.2mm)
Release Force 2.000gf
Dimensions
Length 54.3mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
