1-1825010-5
RoHS
/
Package /
Category Switches / Slide Switches
Description
Switch Slide 4PDT Side Slide 0.3A 115VDC PC Pins Thru-Hole Tube
PDF
/
Inventory: 8657
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Silver
Mount Through Hole
Housing Material Polychlorinated
Actuator Material Polyester
Technical
Termination PC Pins
Number of Positions 2
Max Operating Temperature 80°C
Min Operating Temperature -40°C
Orientation Right Angle
Current Rating 300mA
Voltage - Rated AC 115V
Switch Function On-On
Contact Style Shorting
Contact Resistance 40mOhm
ELV Compliant
Electrical Life 15000 cycles
Throw Configuration 4PDT
Max Voltage Rating (DC) 115V
Mechanical Life 15000 cycles
Current Rating (Max) 300mA
Switch Travel 2.79 mm
Dimensions
Length 17.78mm
Length - Tail 4.06mm
Actuator Length 5.84mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
