600SP1S3M3Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
SWITCH SLIDE SPDT 1A 30V
PDF
/
Buying Options
Total Price: USD $5.18
Unit Price: USD $5.176765
≥1 USD $5.176765
≥200 USD $2.066505
≥500 USD $1.996921
≥1000 USD $1.962786
Inventory: 3006
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole, Right Angle
Actuator Material Polybutylene Terephthalate (PBT)
Technical
Operating Temperature -40°C~80°C
Packaging Bulk
Published 2008
Series 600
Feature IP67 - Dust Tight, Waterproof
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Number of Positions 2
Voltage - Rated DC 30V
Current Rating (Amps) 1A DC
Current Rating 1A
Contact Finish Silver
Termination Style PC Pin
Body Length or Diameter 13.9954mm
Body Breadth 7.7978 mm
Actuator Type Standard
Circuit SPDT
Switch Function On-On
Contact Resistance 0.1mOhm
Insulation Resistance 1000000000Ohm
Contact Current(DC)-Max 1A
Sealing EPOXY
Electrical Life 20,000 Cycles
Mechanical Life 20,000 Cycles
Switch Type SLIDE SWITCH
Contact Current(AC)-Max 1A
Contact (AC) Max Rating R Load 1A@250VAC
Contact Timing Not Specified
Contact (DC) Max Rating R Load 1A@30VDC
Contact Voltage(AC)-Max 250V
PCB Hole Count 3
Switch Travel 4.00mm
Dimensions
Body Height 7.6962mm
Length - Termination 0.169 inch
Actuator Length 2.30mm
Compliance
RoHS Status ROHS3 Compliant
