600DP1S1M2Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
SWITCH SLIDE DPDT 1A 30V
PDF
/
Buying Options
Total Price: USD $6.15
Unit Price: USD $6.146998
≥1 USD $6.146998
≥200 USD $2.452497
≥500 USD $2.371097
≥1000 USD $2.330398
Inventory: 7794
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Termination 0.169 inch
Body Height 7.6962mm
Technical
Switch Travel 4.00mm
PCB Hole Count 6
Contact Voltage(AC)-Max 250V
Contact (DC) Max Rating R Load 1A@30VDC
Contact Timing Not Specified
Contact (AC) Max Rating R Load 1A@250VAC
Contact Current(AC)-Max 1A
Switch Type SLIDE SWITCH
Mechanical Life 20,000 Cycles
Electrical Life 20,000 Cycles
Sealing EPOXY
Contact Current(DC)-Max 1A
Insulation Resistance 1000000000Ohm
Contact Resistance 0.1mOhm
Switch Function On-On
Circuit DPDT
Actuator Type Recessed
Body Breadth 7.7978 mm
Body Length or Diameter 13.9954mm
Termination Style PC Pin
Contact Finish Silver
Current Rating 1A
Current Rating (Amps) 1A DC
Voltage - Rated DC 30V
Number of Positions 2
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature IP67 - Dust Tight, Waterproof
Series 600
Published 2008
Packaging Bulk
Operating Temperature -40°C~80°C
Physical
Actuator Material Polybutylene Terephthalate (PBT)
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 9 Weeks
