GI-152-0079

CW Industries
RoHS
RoHS RoHS compliant
Package /
Category Switches / Slide Switches
Description SWITCH SLIDE DPDT 3A 125V
PDF
/
Inventory: 6353
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Contact Material Copper
Mount Through Hole
Mounting Type Through Hole, Right Angle
Housing Material STEEL
Actuator Material Polyamide (PA66), Nylon 6/6

Technical

Operating Temperature -10°C~104°C
Packaging Bulk
Series GI
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Number of Positions 1
Voltage - Rated DC 125V
Current Rating (Amps) 3A AC 500mA DC
Current Rating 3A
Contact Finish Silver
Termination Style PC Pin
Voltage - Rated AC 125V
Body Length or Diameter 18.796mm
Body Breadth 6.9342 mm
Actuator Type Standard
Circuit DPDT
Switch Function On-On
Contact Resistance 0.01mOhm
Contact Current(DC)-Max 0.5A
Electrical Life 6,000 Cycles
Mechanical Life 10,000 Cycles
Switch Type SLIDE SWITCH
Contact Current(AC)-Max 0.5A
Contact (AC) Max Rating R Load 0.5A@125VAC
Contact Timing Not Specified
Contact (DC) Max Rating R Load 0.5A@125VDC
PCB Hole Count 9
Actuator Color BLACK
Switch Travel 3.30mm

Dimensions

Body Height 10.2616mm
Length - Termination 0.25 inch
Actuator Length 11.50mm

Compliance

RoHS Status ROHS3 Compliant
