V80213MS02Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
SWITCH SLIDE DPDT 10A 125V
PDF
/
Buying Options
Total Price: USD $4.2
Unit Price: USD $4.1976
≥1 USD $4.1976
≥10 USD $4.00576
≥100 USD $3.395392
≥500 USD $3.358256
Inventory: 1179
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper
Mount Through Hole
Mounting Type Through Hole
Body Material Nylon
Actuator Material Polyester, Glass Filled
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series V
Feature No Marking
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Voltage - Rated DC 30V
Current Rating (Amps) 10A AC 4A DC
Orientation Vertical
Depth 16.5mm
Current Rating 10A
Contact Finish Silver
Termination Style PC Pin
Voltage - Rated AC 125V
Approval Agency CSA, UL, VDE
Actuator Type Screwdriver Slot
Circuit DPDT
Switch Function On-On
Max Voltage Rating (AC) 250V
Max Current Rating 10A
Electrical Life 10,000 Cycles
Max Voltage Rating (DC) 28V
Contact Current Rating 10A
Illumination Type Non-Illuminated
Contact Timing Not Specified
Dimensions
Length 26.19mm
Actuator Length Flush
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
