1203M2S3AQE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
C & K COMPONENTS 1203M2S3AQE2 Slide Switch, 1000 Series, DPDT, On-Off-On, Through Hole, 6 A, 250 V
PDF
/
Buying Options
Total Price: USD $19.47
Unit Price: USD $19.472933
≥1 USD $19.472933
Inventory: 8252
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Actuator Length 4.72mm
Width 12.7mm
Length 13.57mm
Technical
Switch Travel 2.16mm
Contact Timing Not Specified
Contact Current Rating 6A
Max Voltage Rating (DC) 28V
Throw Configuration DPDT
Electrical Life 40,000 Cycles
Max Current Rating 6A
Max Voltage Rating (AC) 250V
Insulation Resistance 1GOhm
Contact Resistance 10mOhm
Switch Function On-Off-On
Circuit DPDT
Actuator Type Standard
Voltage - Rated AC 120V
Termination Style PC Pin
Contact Finish Silver
Current Rating 6A
Depth 22.49mm
Orientation Horizontal, Right Angle
Current Rating (Amps) 6A AC/DC
Voltage - Rated DC 28V
Min Operating Temperature -30°C
Max Operating Temperature 65°C
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Black Actuator, Epoxy Sealed Terminals
Series 1000
Published 2006
Packaging Bulk
Operating Temperature -30°C~65°C
Physical
Actuator Material Polyamide (PA), Nylon
Housing Material Stainless Steel
Mounting Type Through Hole, Right Angle
Mount Brackets, Through Hole
Contact Plating Silver
Contact Material Copper
Supply Chain
Factory Lead Time 16 Weeks
