1201M2S3AV2BE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
SWITCH SLIDE DPDT 0.4VA 20V
PDF
/
Buying Options
Total Price: USD $5.77
Unit Price: USD $5.772821
≥1 USD $5.772821
Inventory: 1172
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Actuator Length 4.72mm
Length 11.43mm
Technical
Switch Travel 2.16mm
Contact Timing Not Specified
Max Voltage Rating (DC) 20V
Electrical Life 100,000 Cycles
Max Voltage Rating (AC) 20V
Switch Function On-On
Circuit DPDT
Actuator Type Standard
Voltage - Rated AC 20V
Termination Style PC Pin
Contact Finish Gold
Depth 23.06mm
Orientation Right Angle
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Black Actuator, Epoxy Sealed Terminals
Series 1000
Published 2008
Packaging Tray
Operating Temperature -30°C~65°C
Physical
Actuator Material Polyamide (PA), Nylon
Housing Material Stainless Steel
Mounting Type Through Hole, Right Angle, Vertical
Mount Brackets, Through Hole, Vertical
Contact Material Copper
Supply Chain
Factory Lead Time 16 Weeks
