MMS42
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
Standard MMS Through Hole Bulk Slide Switch 2.00mm 300mA 30V .3A@30VDC
PDF
/
Inventory: 8288
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Actuator Material Polybutylene Terephthalate (PBT)
Technical
Operating Temperature -20°C~70°C
Packaging Bulk
Series MMS
JESD-609 Code e4
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Additional Feature LOW PROFILE
HTS Code 8536.50.90.50
Voltage - Rated DC 30V
Current Rating (Amps) 300mA DC
Orientation Straight
Current Rating 300mA
Contact Finish Silver
Termination Style PC Pin
Body Length or Diameter 16mm
Body Breadth 7 mm
Actuator Type Standard
Circuit 4PDT
Switch Function On-On
Contact Resistance 25mOhm
Contact Current(DC)-Max 0.3A
Sealing EPOXY TERMINAL SEALED
Electrical Life 10,000 Cycles
Max Voltage Rating (DC) 30V
Switch Type SLIDE SWITCH
Contact Current Rating 300mA
Contact Timing Not Specified
Contact (DC) Max Rating R Load .3A@30VDC
Dimensions
Body Height 5.5mm
Actuator Length 2.00mm
Compliance
RoHS Status ROHS3 Compliant
