2215/22VI100
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Single Conductor Cables (Hook-Up Wire)
Description
HOOK-UP STRND 22AWG VIOLET 100'
PDF
/
Buying Options
Total Price: USD $0.2
Unit Price: USD $0.202187
≥1 USD $0.202187
Inventory: 2524
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Physical
Insulation Material PVC
Conductor Material Copper, Tinned
Jacket (Insulation) Material Poly-Vinyl Chloride (XLPVC), Irradiated
Technical
Operating Temperature -55°C~105°C
Packaging Spool
Published 2014
Series MIL-W-16878 Type C
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color Violet
Wire Gauge 22 AWG
Voltage 1000V
Cable Type Hook-Up
Wire/Cable Type Hook-Up
Wire/Cable Gauge 22 AWG
Jacket Color Violet
Conductor Strand 7/30
Jacket (Insulation) Diameter 0.062 (1.57mm)
Insulation Diameter 1.5748 mm
Dimensions
Length 100.0' 30.5m
Jacket (Insulation) Thickness 0.016 0.41mm
Insulation Thickness 406.4μm
Compliance
RoHS Status ROHS3 Compliant
Ratings UL Style 1430
