212-9T2
RoHS
/
Package /
Category Switches / Rotary Switches
Description
Rotary Switches 9 TAPS 20A/150VAC 20VDC 2 IN TANDEM
PDF
/
Inventory: 5866
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Silver Alloy
Mounting Type Panel Mount
Surface Mount NO
Technical
Packaging Bulk
Published 2007
Series 212
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Number of Positions 9
Voltage - Rated DC 20V
Current Rating (Amps) 20A AC/DC
Termination Style Solder Lug
Voltage - Rated AC 150V
Body Length or Diameter 57mm
Actuator Type Flatted (6.35mm Dia)
Panel Cutout Dimensions Circular - 9.53mm Dia
Switch Type ROTARY SWITCH
Number of Decks 2
Operating Force 35 ~ 81gfm
Contact Timing Non-Shorting (BBM)
Index Stops Fixed
Circuit per Deck SP9T
Depth Behind Panel 106.40mm
Index Angle 240 °
Number of Switch Sections 2
Number of Poles per Deck 1
Angle of Throw 30°
Switch Action LATCHED
Dimensions
Actuator Length 12.70mm
Compliance
RoHS Status Non-RoHS Compliant
