50EMPT36-01C05S

Grayhill Inc.
RoHS
RoHS RoHS compliant
Package /
Category Switches / Rotary Switches
Description Rotary Switches Rotary Switch, Metric 4mm shaft, military, PC mount, process sealed, 36-deg;, 1 deck, 2 pole/deck, 5 positions/pole, shorting, 50EMP60-01C05S
PDF
/
Inventory: 2948
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Actuator Length 9.53mm

Technical

Angle of Throw 36°
Number of Poles per Deck 2
Depth Behind Panel 14.63mm
Circuit per Deck DP5T
Index Stops Fixed
Contact Timing Shorting (MBB)
Operating Force 5.761 ~ 17gfm
Number of Decks 1
Max Voltage Rating (DC) 28V
Throw Configuration DP5T
Max Voltage Rating (AC) 220V
Actuator Type Flatted (3.17mm Dia)
Voltage - Rated AC 115V
Termination Style PC Pin
Contact Finish Gold
Current Rating (Amps) 150mA AC 200mA DC
Voltage - Rated DC 28V
Number of Positions 5
Termination PC Pins
Part Status Active
Feature Process Sealed
Series 50

Physical

Mounting Type Panel Mount, Through Hole
Mount Panel, Through Hole
Contact Plating Gold
Contact Material Metal

Supply Chain

Factory Lead Time 16 Weeks
