D7G0111S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
SWITCH ROTARY 2-11POS 1A 115V
PDF
/
Inventory: 9657
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Actuator Length 47.63mm
Technical
Angle of Throw 30°
Number of Poles per Deck 1
Index Angle 30 °
Depth Behind Panel 16.76mm
Circuit per Deck SP11T
Index Stops Adjustable
Contact Timing Shorting (MBB)
Number of Decks 1
Contact Style Shorting
Panel Cutout Dimensions Circular - 9.78mm Dia
Actuator Type Round (6.35mm Dia)
Voltage - Rated AC 115V
Termination Style Solder Lug
Contact Finish Silver
Current Rating 2.25A
Current Rating (Amps) 1A AC 2.25A DC
Voltage - Rated DC 28V
Number of Positions 2 ~ 11
Termination Solder
Part Status Active
Series D7
Published 2006
Physical
Number of Pins 11
Mounting Type Panel Mount
Mount Panel
Contact Plating Silver
Contact Material Brass
